| Tractor Series |
Power Shift Tractor |
| ■ Matching Dongfeng Cummins six cylinder electronic control, high pressure common rail, turbocharger and inter-cooling diesel engine. |
| ■ French McCormich power box chassis with four sections 8 shifts power shift transmission. The gear of the gearbox is 30F+25R |
| ■ Italy CARRARO front axle |
| ■ Electronic control hydraulic lifting system with easy control |
| ■ Adjustable front and rear wheel track, the rear wheel track is stepless adjustable. |
| ■ Using hydraulic steering system, rear axle, differential lock, PTO clutch uses electric hydraulic control with easy control |
| ■ With power take-off and hydraulic lifting control button outside, only one person can hitch farm impletments easily. |
| Trype |
FH22041-D |
| Engine |
Power/speed |
Kw/r/min |
162/2200 |
| Specific Fuel Consumption |
g/kw.h |
/ |
| Drive Type |
/ |
4*4 |
| Dimension(L/W/H) |
mm |
5470*3684(One Tire: Semi-axis 2995)*3350 |
| Wheel Base |
mm |
2950 |
| Track(Front Wheel) |
mm |
1864-2244(Six Degree Adjustable) |
| Track(Rear Wheel) |
mm |
1780-2404(No Degree Adjustable, Double Tires Track:2518) |
| Ground Clearance |
mm |
390 Draft Gear |
| Min.Running Weight |
kg |
8600 |
| Front Traction Force ≤ |
kg |
1000 |
| Traction Force |
kn |
49 |
| Gear Number |
/ |
30F+25R |
| Gear Forward |
Speed |
km/h |
2-36 |
| Gear Reverse |
Speed |
km/h |
2-28 |
| Tires Model |
Front Tires |
/ |
16.9-30R1 |
| Rear Tires |
/ |
20.8-42R1 |
| Format of the power-output shaft |
Type |
/ |
Rear Position and independent |
| Speed |
r/min |
540/1000 |
| Max. Pull-down Piston Pull |
KN |
56 |
